In ancient times, lime was the primary material used in construction. Over the years, as construction evolved, cement and steel became the dominant materials. Today, the construction industry continues to innovate, introducing advanced technologies to improve quality, efficiency, and craftsmanship. Traditionally, masonry work relied on stones, bricks, and concrete blocks, but the introduction of lightweight AAC blocks has transformed modern construction. Just as lime was once replaced by cement and sand, AAC blocks now lead the way, offering superior performance and aligning with the demands of modern construction practices.
TECHNICAL SPECIFICATIONS
| PARAMETER | VALUE |
|---|---|
| COMPRESSIVE STRENGTH | 4N/MM2 (MPA) |
| DRY DENTISY | 550 – 650 KG/M3 |
| WATER ABSORPTION (AT EQUILIBRIUM) | 8% |
| FIRE RESISTANCE | 4 HRS. (FOR 150 MM WALL) |
| THERMAL CONDUCTIVITY | 0.16 W/MOK |
| COEFFICIENT OF THERMAL EXPANSION | 8.1 X 10-6 K-1 |
| DRYING SHRINKAGE | 0.04°,0 |
| SOUND TRANSMISSION CLASS RATING | 43DB FOR 100 MM WALL. |
| MODULUS OF ELASTICITY | 2040 MPA |
CALCULATION SHEET OF AAC BLOCK
| Length (mm) | Height (mm) | Width (mm) | No of Pcs (per cubic meter) | Work in Sq (per cubic meter) |
|---|---|---|---|---|
| 600 | 200 | 100 | 83.33 | 116.33 |
| 600 | 200 | 125 | 66.67 | 93.07 |
| 600 | 200 | 150 | 55.56 | 77.56 |
| 600 | 200 | 200 | 41.67 | 58.17 |
| 600 | 200 | 225 | 37.04 | 51.71 |
RED BRICK VS AAC
| Property | Red Brick | AAC Block |
|---|---|---|
| Material Composition | Top soil | Fly ash / Sand |
| Water Absorption | High | Low |
| Pest & Termite | High | None |
| Dry Density | 1800-2000 kg/m3 | 550-650 kg/m3 |
| Earth Quake Resistant | Low | Highest in this category |
| Wastage due to Breakages | High 10 to 12% | Minimal (1-3% |
| Fire Resistance (6″ wall) | 2 Hours | 4 Hours |
| Energy Saving | Low | High (~25% reduction in air conditioner cost/25-30% less electricity consuption on HVAC) |
| Thermal Conductivity (K value) | 0.81 W/m2.k | 0.16 W/m2.k |
